B3630M

Output Power 输出功率: 1W~16W

Weight 重量: 110g (Approx.)

Brushless DC Motor-Typical Application 无刷直流电机-典型应用

Home Application: Electric door, Electric Window, Electric Curtain,

Electric Awning

家用电器：电动门，电动窗，电动窗帘，电动遮阳棚

Industry Facility: Transmission Equipment, Gear System, Actuator

工业设备：传动机械，齿轮系统，致动器

Electronic Equipment: Electric Valve, Small Switcher, Lighting Adjustor,

Small Percussion Drill

电控设备：电动阀门，小型转换器，灯光调节器，电动扳手

Business Equipment: Electric Gate, Banking Facility, ATM, Vending Machine

商业设备：电动门禁，银行设施，ATM机，售卖机

Personal Care: Massager   个人护理：按摩器

Model

型号

电压 Voltage(V)

No Load 空载

Rated Load 额定负载

Stall 堵转

Operating Range

Rated

Speed (rpm)

Current (A)

Torque (mNm)

Speed (rpm)

Current (A)

Output P. (W)

Torque (mNm)

Current (A)

B3630M-S01

5.8-12

6

2940

0.39

10.00

2270

0.91

2.38

44.05

2.5

B3630M-S02

8-26

12

5200

0.27

14.72

4260

0.90

6.56

81.30

2.5

B3630M-S03

8-26

24

6970

0.20

19.62

5640

0.76

11.58

102.51

2.5

B3630M-S04

8-26

24

15755

0.39

20.00

13213

1.59

27.67

123.9

3.5

Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

注意：上述规格仅针对特定客户，电压、扭矩、转速、电流、功率、输出轴的特征和尺寸等都可以按照客户的特殊要求进行调整。

B3630M-S02                 12V

  B3630M-S03               24V
