D3657M

（DC Motor直流马达）

Output Power 输出功率: 10W~70W

Weight 重量:248g (Approx.)

DC Motor-Typical Application直流电机-典型应用

Automotive Parts: ETC, EPB, Rear Mirror, Sunroof, Seat, Power Tailgate Lift System

汽车部件：ETC，EPB，后视镜，遮阳板，座椅，电动尾门

Model

型号

(DC Motor直流马达)

Voltage(V) 电压

No Load 空载

Rated Load 额定负载

Stall 堵转

Operating Range

Rated

Speed (rpm)

Current (A)

Torque (mNm)

Speed (rpm)

Current (A)

Output P. (W)

Torque (mNm)

Current (A)

D3657M-S01

16-32

24

7387

0.19

49

6274

1.7

32.2

325

10

Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.

注意：上述规格仅针对特定客户，电压、扭矩、转速、电流、功率、输出轴的特征和尺寸等都可以按照客户的特殊要求进行调整。
